Усилители серии PE - больше, чем просто усилители. Шесть 2-канальных моделей предлагают впечатляющий диапазон усиления от 400 до 1900 Вт на канал на 4 Ом, а их возможности Ethernet значительно повышают их значимость в сетевых аудио применениях.
| Rated Power 8 ohms (per channel): | 200W |
| Rated Power 4 ohms (per channel): | 400W |
| Rated Power 2 ohms (per channel): | 700W |
| Rated Power 8 ohms (Bridged): | 800W |
| S/N (20 Hz-20 kHz, unweighted): | >98dB |
| 1/8 Power, Pink Noise, 4 ohms: | 420W |
| 1/8 Idle, Pink Noise 4 ohms: | 9.4A |
| 1/8 Idle, Pink Noise 8 ohms: | 2.4A |
| Outpit Circuitry: | Class-AB |
| Power Cable: | 15A Edison |
| Weight: | 9.98kg |
| Frequency Response (8 ohms): | 20 Hz - 20k Hz, (unweighted) ±0.15dB |
| Distortion (SMPTE, typical): | <0.01% (8 ohm load, 10dB below rated power) |
| Distortion THD+N, typical): | <0.01% (8 ohm load, 10dB below rated power) |
| Input Impedance: | 20k ohms, balanced |
| Input Gain: | 26dB, 32dB or 1.5V |
| Maximum Input Level: | +21dBu |
| Damping Factor: | >400 (8 ohm load) |
| Cooling: | Temperature dependent speed controlled fan, Front-in, Rear-out flow |
| Control Network: | onboard, standard 10/100 Ethernet |
| Connectors (each channel): | Input - XLR female/TRS, Euroblock, XLR male (looping) Output - Speakon, Screw terminal (800, 1200) Speakon (1800, 2400, 3000, 3800) |
| Front Controls: | AC Power Switch, Individual input attenuators |
| Front indicators (LED color): | per channel: Clip, -6dB, -12dB, -18dB, Temp, Current Power, Standby, Bridge Mono, Parallel Mono, Comm |
| Amplifier and Load Protection: | inrush current limitation, temperature monitoring heat-sinks, output DC protection, power transistor SOA protection, output over-current protection, mains fuses protection |
| Dimensions: | Height: 3.50'' (88.9mm) 2RU, Width: 19'' (483 mm), Depth: 15.5'' (394mm) |
| Environmental: | 4-49°C noncondensing |
